Lowest Common Ancestor in Binary Tree: A practical guide

The lowest common ancestor (LCA) in a binary tree is a fundamental concept in computer science and algorithms. It refers to the deepest node in the tree that has both given nodes as descendants, where a node can be a descendant of itself. Day to day, understanding this concept is crucial for solving various tree-based problems efficiently and is widely used in areas such as network routing, genealogy, and data structure design. This guide explores the problem of finding the LCA in a binary tree, discusses different approaches to solve it, provides code examples, and examines their time and space complexities Surprisingly effective..

Problem Statement

Given a binary tree and two nodes, node1 and node2, the task is to find their lowest common ancestor. As an example, consider the binary tree below:

        1
       / \
      2   3
     / \   \
    4   5   6

If node1 = 4 and node2 = 5, their LCA is 2. Even so, if node1 = 4 and node2 = 6, the LCA is 1.

Approaches to Find LCA in a Binary Tree

1. Recursive Approach

The recursive approach is intuitive and leverages the tree's structure to trace back from the nodes to the root. The algorithm works as follows:

• Base Case: If the current node is None, return None.
• Check Current Node: If the current node is one of the target nodes (node1 or node2), return the current node.
• Recursively Search Subtrees: Traverse the left and right subtrees.
• Determine LCA:
  • If both subtrees return non-None values, the current node is the LCA.
  • If only one subtree returns a non-None value, propagate that value upward (indicating one node is an ancestor of the other).

Code Example (Python):

class TreeNode:
    def __init__(self, val=0, left=None, right=None):
        self.val = val
        self.left = left
        self.right = right

def find_lca(root, node1, node2):
    if not root:
        return None
    if root == node1 or root == node2:
        return root
    left_lca = find_lca(root.left, node1, node2)
    right_lca = find_lca(root.right, node1, node2)
    if left_lca and right_lca:
        return root
    return left_lca if left_lca else right_lca

Time and Space Complexity:

• Time: O(n), where n is the number of nodes (worst-case traversal of the entire tree).
• Space: O(h), where h is the tree height (due to recursion stack).

2. Iterative Approach Using Stack

An iterative solution avoids recursion by using a stack to simulate traversal. This method tracks the path from the root to each node and then identifies the last common node in both paths But it adds up..

Steps:

1. Use a stack to perform depth-first search (DFS) and record the path to each target node.
2. Compare the paths to find the last common node.

Code Example (Python):

def find_path(root, target, path):
    if not root:
        return False
    path.append(root)
    if root == target:
        return True
